Artikelnummer
675100515
MXN 22 C Color/ auto heated infra red ball camera 130°
€ 389,95
Op voorraad
"'
- Snelle verzending
- Producten van hoge kwaliteit
- Veilige betalingen
Dode-hoekcamera kleur, infrarood, beeldhoek 130°, met ingebouwde verwarming IP69k
• 1/3” color CCD high resolution image sensor • IP69K waterproof rating • Built-in IR LED’s • Diagonal 20° (MXN22C-020) 40° (MXN22C-040) 78° (MXN22C-078) or 130° (MXN22C) viewing • Auto iris • Normal/Mirror image adjustable • Built-in microphone (for one-way audio) • Multi purpose (frontview, sideview, rearview, surveillance, etc) • Built-in automatic heater (below +10°C) • Anti-corrosive 3-fold coating • Temp. -40°C ~ 80°C • Vibration resistant (10G) • CE marked • EMC approved
SPECIFICATIONS Image sensor : Picture elements : Resolution : S/N ratio : Minimum illumination : Power range : Power consumption :
Operating temperature : Diagonal viewing angle :
Dimension : Weight :
MXN22C 1/3” Sony super HAD color CCD 470.000 pixels (PAL) 520 TV lines Minimum 44dB (at AGC off) 0 lux (IR LED’s on) DC 9 ~ 28V DC 12V, 350mA (heater on) DC 12V, 110mA (heater off) -40°C to +80°C MXN22C-020: 20°(D) x 16°(H) x 13°(V) MXN22C-040: 40°(D) x 29°(H) x 22°(V) MXN22C-078: 78°(D) x 62°(H) x 46°(V) MXN22C: 100°(H)x73°(V)x130°(D) Ø 52 mm, 72(W) x 51(D) x 63(H) incl. bracket Approx. 215g
• 1/3” color CCD high resolution image sensor • IP69K waterproof rating • Built-in IR LED’s • Diagonal 20° (MXN22C-020) 40° (MXN22C-040) 78° (MXN22C-078) or 130° (MXN22C) viewing • Auto iris • Normal/Mirror image adjustable • Built-in microphone (for one-way audio) • Multi purpose (frontview, sideview, rearview, surveillance, etc) • Built-in automatic heater (below +10°C) • Anti-corrosive 3-fold coating • Temp. -40°C ~ 80°C • Vibration resistant (10G) • CE marked • EMC approved
SPECIFICATIONS Image sensor : Picture elements : Resolution : S/N ratio : Minimum illumination : Power range : Power consumption :
Operating temperature : Diagonal viewing angle :
Dimension : Weight :
MXN22C 1/3” Sony super HAD color CCD 470.000 pixels (PAL) 520 TV lines Minimum 44dB (at AGC off) 0 lux (IR LED’s on) DC 9 ~ 28V DC 12V, 350mA (heater on) DC 12V, 110mA (heater off) -40°C to +80°C MXN22C-020: 20°(D) x 16°(H) x 13°(V) MXN22C-040: 40°(D) x 29°(H) x 22°(V) MXN22C-078: 78°(D) x 62°(H) x 46°(V) MXN22C: 100°(H)x73°(V)x130°(D) Ø 52 mm, 72(W) x 51(D) x 63(H) incl. bracket Approx. 215g
| Accessoiremerk | MXN |
|---|---|
| Barcode | 8809338840126 |
| Adviesverkoopprijs incl. BTW | € 325,00 |
| Camera, Monitor eigenschap | Infrarood, IP genormeerd, Normaal beeld, Spiegelbeeld, Verwarmd |
| Camera montage | Opbouw |
| Camera video systeem | PAL - EU 50 Hz 25 fps |
| Camera connector | MXN 4-PIN connector |
| Camera lens type | CCD (Sony) Super HAD II |
| Camera kijkhoek | 130° |
| Input Voltage | 12/24V geschikt |
| Aanvullend product benodigd | Kies de gewenste verleng- of verloopkabel via het verwante producten tabblad. Een monitor completeert de installatie |
| Veiligheid (productinfo) | Het gebruik van een camera(systeem) biedt een optimale veiligheid, u heeft beter (in)zicht in wat er zich rondom uw auto bevindt en u kunt daardoor ongelukjes en schade voorkomen. |
